CLEANCUBE Mini is the perfect pre-fabricated cleanroom solution for organisations who need that extra bit of laboratory or manufacturing space but are restricted by the footprint of their existing premises.
Our 20ft shipping container Cleancube Mini cleanroom models are being set up in external spaces such as car parks and unused land, as well as within factory and warehouse facilities all over the UK, allowing businesses to continue their operations despite space limitations or restrictions on existing host buildings.
Mini base models are feature three rooms as standard – one process room, a Personnel Airlock and a plant room, with a choice of three internal ceiling heights.
Speak to a member of the Cleancube about the different options you have to deck out your unit internally and externally to fully meet the complex needs of your application.
Mini Model Technical Data
Key Information
- External Shell 1 × 20ft high cube steel container
- External Dimensions 6,058mm (L) × 2,438mm (W) × 2,896mm (H)
- Shell Colour Blue as standard (sprayed on request)
- Branding Printed vinyl graphics or full wraps
- Cladding Can be larch clad on request
- Number Of Rooms 3
- Personnel Airlock 1,409mm x 2,038mm x 2,200mm
- Process Area 3,000mm x 2,038mm × 2,200mm
- Plant Room 1,000mm × 2,038mm × 2,200mm
- Total Weight Approximately 3,000kg
- Internal Fit-out Choose from the 3 internal Specification levels below:
- – GMP: For GMP Specification information Click here
- – ISO: For ISO Specification information Click here
- – CNC: For CNC Specification information Click here
Standard Features
- Classifications Available Laboratory (CNC), BSL1, BSL2, BSL2+, BSL3, ISO8, ISO7, ISO6, ISO5, Grade D, Grade C, Grade B
- Ceiling Heights Available 2.2m as standard – 2.5m vault sections can be implemented for equipment installations
- Walls & Ceiling Constructed from modular composite panels
- Doors 3 x Single personnel doors
- Flooring Vinyl (ESD also available)
- Power & Network 9 x 13-amp double sockets and 5 x CAT6 data outlets
- Lighting 2 x flush mounted LED Lights (500 Lux), plus additional wall-mounted lighting in Plant room
- Air Conditioning 21C +/- 2C and 50% RH +/- 10%
- Furniture Full fit-out available. To view the range click here
- Equipment Full fit-out available. To view the range click here
- Other Utilities Available: Compressed air, drainage, town’s water supply, extraction, process gasses
CLEANCUBE MINI 2D LAYOUT
A full 2D drawing pack will be issued outlining all structural, mechanical & electrical general arrangements, with elevations also provided and further specific layouts for client furniture & equipment. 3D models are also produced in SolidWorks and Revit.
