IF ONE 40ft Midi shipping container cleanroom doesn’t quite give you the footprint your application requires, then the Maxi 2 is sure to deliver exactly what you need.

Featuring two 40ft containers securely conjoined, the Maxi 2 boasts two impressively large 16m² process areas – giving you more flexibility than ever before to take your operation to the next level whilst still enjoying the benefits of a portable, pre-fabricated cleanroom.

Below is a representation of what a user can expect from a standard Cleancube Maxi 2 – however, the Guardtech team are on hand to help you tailor your Cleancube to meet the specific needs of your organisation.

Maxi 2 base models feature four rooms as standard – one process room, a Personnel Airlock and a plant room, with a choice of three internal ceiling heights.

Speak to a member of the Cleancube about the different options you have to deck out your unit internally and externally to fully meet the complex needs of your application.

Maxi 2 Model Technical Data

Key Information

  • External Shell 2 x 40ft high cube steel containers (conjoined)
  • External Dimensions 12,192mm (L) x 4,876mm (W) x 2,896mm (H)
  • Shell Colour Blue as standard (sprayed on request)
  • Branding Printed vinyl graphics or full wraps
  • Cladding Can be larch clad on request
  • Number Of Rooms 4
  • Personnel Airlock/Materials Airlock (PAL/MAL) 3,047mm x 2,138mm x 2,200mm
  • Process Area 1 4,340mm x 4,476mm x 2,200mm
  • Process Area 2 4,340mm x 4,476mm x 2,200mm
  • Plant Room 3,047mm x 2,138mm x 2,200mm
  • Total Weight Approximately 12,000kg
  • Internal Fit-out Choose from the 3 internal Specification levels below:
  • GMP: For GMP Specification information Click here
  • ISO: For ISO Specification information Click here
  • CNC: For CNC Specification information Click here

Standard Features

  • Classifications Available Laboratory, BSL1, BSL2, BSL2+, BSL3, ISO8, ISO7, ISO6, ISO5, Grade D, Grade C, Grade B
  • Ceiling Heights Available 2.2m as standard – 2.5m vault sections can be implemented for equipment installations
  • Walls & Ceiling Constructed from modular composite panels
  • Doors 3 x Double personnel doors, 2 x Single personnel doors, 1 x Fire escape
  • Flooring Vinyl (ESD also available)
  • Power & Network 16 x 13-amp double sockets and 8 x CAT6 data outlets
  • Lighting 9 x flush mounted LED Lights (500 Lux), plus additional wall-mounted lighting in Plant room
  • Air Conditioning 21C +/- 2C and 50% RH +/- 10%
  • Furniture Full fit-out available. To view the range click here
  • Equipment Full fit-out available. To view the range click here
  • Other Utilities Available: Compressed air, drainage, town’s water supply, extraction, process gasses

CLEANCUBE Maxi 2 2D LAYOUT

A full 2D drawing pack will be issued outlining all structural, mechanical & electrical general arrangements, with elevations also provided and further specific layouts for client furniture & equipment. 3D models are also produced in SolidWorks and Revit.
